Two housings cover the whole torque range.
Every wireless torque transducer in the TT series shares one accuracy spec and one part-number scheme. What actually changes from model to model is the housing on the output end, and that is what decides the torque range it is built for.
Housing and torque range
| Housing | Torque range | Example | Built for |
|---|---|---|---|
| Square drive & hex socket | 50 – 2000 N·m | TTEH-1000, TTES-500 | The housing on TTES, TTAS, TTEH and TTAH series — square drive or hex socket output, sized to fit an impact wrench or torque wrench in this range. |
| Bit holder | 5 – 20 N·m | TTEB-20 | The TTEB series housing — a hex 6.35 mm bit holder, sized for screwdrivers and small fasteners rather than a socket wrench. |
Measured range, resolution, accuracy, wireless and battery are the same across every housing — see the full specification on any product page below. Only the torque range and the output fitting change.
Go to the product
TTES series
Full specification and the part-number breakdown for this housing.
View the product → 50 – 2000 N·mTTEH series
Full specification and the part-number breakdown for this housing.
View the product → 5 – 20 N·mTTEB series
Full specification and the part-number breakdown for this housing.
View the product →Not sure which housing you need?
Send the fastener size and the torque you are targeting. A product engineer replies with the model.
